Hitachi
BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Max Speed | 10.3 mph |
|---|---|
| Fuel Capacity | 31.8 gal |
| Spray Water Capacity | 177.0 gal |
Engine
| Engine Model | AA-4JG1T |
|---|---|
| Displacement | 187 in³ |
| Power Measured @ | 2,150 rpm |
| Net Power | 75.0 hp |
| Number of Cylinders | 4 |
Weights
| Operating Weight - standard | 22,134 lb |
|---|---|
| Operating Weight - max ballast | 31,063 lb |
| Max Static Linear Load - Drive Drum | 21 lb-ft |
| Max Static Linear Load - guide drum | 21 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 134 in |
| Overall Length | 17 in |
| Overall Width | 83 in |
| Height - Top of ROPS/FOPS | 125 in |
| Height | 103 in |
| Drum Diameter - Front | 65 in |
| Drum Diameter - Rear | 65 in |
