Hitachi
Komatsu
D65EX-15SL
Crawler Dozer
19 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 37,567 lb |
|---|---|
| Fuel Capacity | 91.2 gal |
| Cooling System Fluid Capacity | 10.6 gal |
| Final Drives Fluid Capacity | 4.8 gal |
| Engine Oil Capacity | 4.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | 8365T |
|---|---|
| Displacement | 494 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 165.0 hp |
| Net Power | 167.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 503 lb-ft |
Hydraulic System
| Pump Flow Capacity | 42.8 gal/min |
|---|---|
| Relief Valve Pressure | 2,702 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 124 in |
| Length of Track on Ground | 103 in |
| Width Over Tracks | 103 in |
| Length w/ Blade | 204 in |
| Length w/o Blade | 155 in |
Transmission
| Max Speed - Forward | 6.0 mph |
|---|---|
| Max Speed - Reverse | 7.2 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Track Gauge | 74 in |
|---|---|
| Number of Track Rollers per Side | 7 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 22 in |
| Track Pitch | 8 in |
Standard Blade
| Width | 132 in |
|---|---|
| Height | 53 in |
| Capacity | 5.00 yd³ |
