Hitachi
JCB
HYDRADIG 110W
Excavator
59 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 37,148 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 66.6 gal/min |
| Hydraulic System Fluid Capacity | 39.7 gal |
| Hydraulic System Relief Valve Pressure | 4,641 psi |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 4.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | A - 4BG 1 TPG |
|---|---|
| Displacement | 263 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 102.0 hp |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 110 in |
| Length of Track on Ground | 130 in |
| Tail Swing Radius | 97 in |
| Width to Outside of Tracks | 107 in |
| Removal Counterweight Clearance | 37 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 86 in |
| Number of Track Rollers per Side | 2 |
| Max Travel Speed | 3.3 mph |
| Shoe Size | 20 in |
| Number of Carrier Rollers per Side | 8 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 197 in |
|---|---|
| Max Reach Along Ground | 313 in |
| Max Loading Height | 257 in |
| Max Vertical Wall Digging Depth | 192 in |
| Max Cutting Height | 369 in |
| Shipping Length of Unit | 331 in |
| Shipping Height of Unit | 117 in |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.29 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
