Specifications
59 data points
Operating Specifications
| Operating Weight | 22,505 lb |
|---|---|
| Fuel Capacity | 41.5 gal |
| Hydraulic Pump Flow Capacity | 41.9 gal/min |
| Hydraulic System Fluid Capacity | 50.2 gal |
| Hydraulic System Relief Valve Pressure | 4,061 psi |
| Engine Oil Capacity | 3.7 gal |
| Cooling System Fluid Capacity | 7.4 gal |
| Hydraulic Pump Type | Electronically controlled system using two variable displacement piston pumps plus twin gear pumps for steering brakes and cooling |
Engine
| Engine Model | JCB EcoMAX 444 TCA EU Stage IV EPA Tier 4 Final compliant |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 109.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,500 rpm |
| Engine Type | 4-stroke 4-cylinder in-line common rail direct injection turbocharged and intercooled diesel |
| Alternator | 150 A |
| Air filter type | Dry element with secondary safety element and in-cab warning sensor |
| Rated Power | 109.0 hp |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 119 in |
| Wheelbase | 104 in |
| Overall Width | 95 in |
Transmission
| Max Travel Speed | 24.9 mph |
|---|
Boom/Stick Excavator Option 1
| Max Digging Depth | 174 in |
|---|---|
| Max Reach Along Ground | 316 in |
Bucket
| Maximum Bucket Capacity | 0.50 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.10 yd³ |
General Specifications
| Operating Weight lbs (kg) | 24,315 (11,029) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 14.5 (4.4) Starting 2025 Model Year |
| Digging Reach ft. (m) | 24.8 (7.5) Starting 2025 Model Year |
| Engine hp (kW) | 109 (81) Starting 2025 Model Year |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 150 in |
|---|---|
| Max Cutting Height | 323 in |
| Max Reach Along Ground | 283 in |
| Max Loading Height | 252 in |
| Shipping Length of Unit | 302 in |
| Shipping Height of Unit | 119 in |
| Max Vertical Wall Dig Depth | 119 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 174 in |
|---|---|
| Max Cutting Height | 347 in |
| Max Reach Along Ground | 307 in |
| Max Loading Height | 275 in |
| Shipping Height of Unit | 119 in |
| Shipping Length of Unit | 305 in |
| Max Vertical Wall Dig Depth | 141 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 133 in |
|---|---|
| Max Cutting Height | 254 in |
| Max Reach Along Ground | 240 in |
| Max Loading Height | 186 in |
| Shipping Height of Unit | 124 in |
| Shipping Length of Unit | 278 in |
| Max Vertical Wall Dig Depth | 72 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 157 in |
|---|---|
| Max Cutting Height | 268 in |
| Max Reach Along Ground | 264 in |
| Max Loading Height | 200 in |
| Shipping Height of Unit | 135 in |
| Shipping Length of Unit | 274 in |
| Max Vertical Wall Dig Depth | 94 in |
