Hitachi

EX1800-3

Mini Excavator

Operating Weight
396,832 lb
Max Digging Depth
234 in
Gross Power
1,000.5 hp
Net Power
901.2 hp
All mini excavators
Hitachi EX1800-3 Mini Excavator
1 / 5
Image 1 of 5
Image: machinio.com

Specifications

48 data points

Operating Specifications

Operating Specifications specifications
Operating Weight396,832 lb
Fuel Capacity719.9 gal
Hydraulic Pump Flow Capacity528.3 gal/min

Engine

Engine specifications
Engine ModelQSK19C
Displacement2,307 in³
Gross Power1,000.5 hp
Net Power901.2 hp
AspirationTurbocharged
Engine MakeCummins

Dimensions

Dimensions specifications
Ground Clearance32 in
Height - Top of Cab272 in
Length of Track on Ground296 in
Tail Swing Radius238 in
Width to Outside of Tracks214 in
Removal Counterweight Clearance79 in

Undercarriage

Undercarriage specifications
Ground Pressure25 psi
Track Gauge181 in
Max Travel Speed1.8 mph
Shoe Size32 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth234 in
Max Loading Height410 in
Max Cutting Height574 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed5 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth324 in
Max Cutting Height563 in
Max Loading Height355 in
Max Vertical Wall Digging Depth219 in
Max Reach Along Ground582 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth366 in
Max Cutting Height569 in
Max Loading Height361 in
Max Reach Along Ground617 in
Max Vertical Wall Digging Depth263 in

Boom/Stick Excavator Option 4

Boom/Stick Excavator Option 4 specifications
Max Digging Depth425 in
Max Cutting Height591 in
Max Loading Height385 in
Max Reach Along Ground674 in
Max Vertical Wall Dig Depth295 in

Boom/Stick Excavator Option 5

Boom/Stick Excavator Option 5 specifications
Max Digging Depth466 in
Max Cutting Height683 in
Max Reach Along Ground750 in
Max Loading Height465 in
Max Vertical Wall Dig Depth398 in

Boom/Stick Excavator Option 6

Boom/Stick Excavator Option 6 specifications
Max Digging Depth526 in
Max Cutting Height713 in
Max Reach Along Ground809 in
Max Loading Height498 in
Max Vertical Wall Dig Depth435 in
