Hitachi
Caterpillar
319C LN
Excavator
54 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 75,508 lb |
|---|---|
| Fuel Capacity | 148.0 gal |
| Hydraulic Pump Flow Capacity | 137.4 gal/min |
| Hydraulic System Fluid Capacity | 84.6 gal |
| Hydraulic System Relief Valve Pressure | 4,641 psi |
| Engine Oil Capacity | 9.3 gal |
| Cooling System Fluid Capacity | 10.4 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | 6SD1T |
|---|---|
| Displacement | 600 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 237.4 hp |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 120 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 131 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 50 in |
Undercarriage
| Ground Pressure | 10 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 256 in |
|---|---|
| Max Reach Along Ground | 398 in |
| Max Loading Height | 277 in |
| Max Vertical Wall Digging Depth | 248 in |
| Max Cutting Height | 391 in |
| Shipping Length of Unit | 435 in |
| Shipping Height of Unit | 126 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
