Hitachi

EX5500-6

Mini Excavator

Gross Power
2,800.0 hp
Net Power
2,666.0 hp
All mini excavators
Hitachi EX5500-6 Mini Excavator
1 / 5
Image 1 of 5
Image: comiskeyminingservices.com.au

Specifications

42 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity2,984.9 gal
Hydraulic System Fluid Capacity3,275.4 gal
Operating Voltage24 V
Alternator Supplied Amperage140 A
Engine Oil Capacity79.3 gal
Cooling System Fluid Capacity251.5 gal
Swing Speed3 rpm

Engine

Engine specifications
Displacement6,102 in³
Power Measured @1,800 rpm
Gross Power2,800.0 hp
Net Power2,666.0 hp
Number of Cylinders32
AspirationTurbocharged and Aftercooled

Dimensions

Dimensions specifications
Height - Top of Cab340 in
Length of Track on Ground276 in
Tail Swing Radius313 in
Upper Structure Ground Clearance119 in
Length of Tracks369 in
Height of Tracks108 in

Undercarriage

Undercarriage specifications
Track Gauge236 in
Max Travel Speed1.5 mph
Number of Upper Rollers3
Loading Shovel Operating Weight1,150,813 lb
Loading Shovel Shoe Width55 in
Loading Shovel Ground Pressure34 psi
Number of Lower Rollers7
Backhoe Shoe Width 155 in
Backhoe Operating Weight - Shoe 11,150,813 lb
Backhoe Ground Pressure - Shoe 134 psi
Number of Track Shoes per Side39

Bucket

Bucket specifications
Reference Bucket Capacity35.39 yd³

Loading Shovel

Loading Shovel specifications
Max Dig Depth180 in
Max Dig Reach654 in
Max Cutting Height745 in
Max Dump Height516 in
Arm Crowd Force352,995 lb-ft

Backhoe Boom / Stick 1

Backhoe Boom / Stick 1 specifications
Max Dig Depth355 in
Max Cutting Height811 in
Max Dump Height512 in
Max Reach on Ground792 in
Max Vertical Wall Dig Depth217 in
Arm Crowd Force275,996 lb-ft
