Hitachi

EX600-6

Mini Excavator

Gross Power
1,944.0 hp
Net Power
1,944.0 hp
All mini excavators
Hitachi EX600-6 Mini Excavator
1 / 5
Image 1 of 5
Image: hitachicm.com

Specifications

35 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity1,967.9 gal
Hydraulic System Fluid Capacity1,056.6 gal
Operating Voltage24 V
Alternator Supplied Amperage140 A
Engine Oil Capacity144.0 gal
Cooling System Fluid Capacity162.3 gal
Swing Speed3 rpm

Engine

Engine specifications
Engine ModelQSKTA60-CE
Displacement3,662 in³
Gross Power1,944.0 hp
Net Power1,944.0 hp

Dimensions

Dimensions specifications
Height - Top of Cab308 in
Length of Track on Ground263 in
Upper Structure Ground Clearance97 in
Length of Tracks343 in

Undercarriage

Undercarriage specifications
Max Travel Speed1.4 mph
Number of Upper Rollers—
Loading Shovel Operating Weight795,869 lb
Loading Shovel Shoe Width50 in
Loading Shovel Ground Pressure28 psi
Number of Lower Rollers8
Backhoe Shoe Width 150 in
Backhoe Operating Weight - Shoe 1791,460 lb
Backhoe Ground Pressure - Shoe 127 psi
Number of Track Shoes per Side—

Loading Shovel

Loading Shovel specifications
Max Dig Depth155 in
Max Dig Reach600 in
Max Cutting Height642 in
Max Dump Height433 in
Loading ShovelBE-Boom length 2570 millimeters height 2350 millimeters width 2570 millimeters / Arm length 5100 millimeters height 2070 millimeters width 2900 millimeters

Backhoe Boom / Stick 1

Backhoe Boom / Stick 1 specifications
Max Dig Depth339 in
Max Cutting Height697 in
Max Dump Height457 in
Max Reach on Ground694 in
Max Vertical Wall Dig Depth161 in
