Tata Hitachi
Caterpillar
5130B
Mini Excavator
16 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Fuel Capacity | 951.0 gal |
|---|---|
| Swing Speed | 4 rpm |
Engine
| Engine Model | QSK45-C |
|---|---|
| Displacement | 2,746 in³ |
| Gross Power | 1,350.5 hp |
| Net Power | 1,302.2 hp |
Dimensions
| Height - Top of Cab | 277 in |
|---|---|
| Length of Track on Ground | 241 in |
| Upper Structure Ground Clearance | 89 in |
| Length of Tracks | 311 in |
| Height of Tracks | 81 in |
Undercarriage
| Max Travel Speed | 1.5 mph |
|---|---|
| Loading Shovel Operating Weight | 526,905 lb |
| Loading Shovel Shoe Width | 39 in |
| Loading Shovel Ground Pressure | 25 psi |
| Backhoe Shoe Width 1 | 39 in |
| Backhoe Operating Weight - Shoe 1 | 533,519 lb |
| Backhoe Ground Pressure - Shoe 1 | 25 psi |
Loading Shovel
| Max Dig Depth | 148 in |
|---|---|
| Max Dig Reach | 554 in |
| Max Cutting Height | 592 in |
| Max Dump Height | 408 in |
Backhoe Boom / Stick 1
| Max Dig Depth | 339 in |
|---|---|
| Max Cutting Height | 637 in |
| Max Dump Height | 408 in |
| Max Reach on Ground | 650 in |
| Max Vertical Wall Dig Depth | 200 in |
