Hitachi

EX2500

Mini Excavator

Gross Power
1,350.0 hp
Net Power
1,302.0 hp
All mini excavators
Hitachi EX2500 Mini Excavator
1 / 5
Image 1 of 5
Image: smsmining.com.au

Specifications

45 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity951.0 gal
Hydraulic System Fluid Capacity779.3 gal
Operating Voltage24 V
Alternator Supplied Amperage150 A
Engine Oil Capacity68.7 gal
Cooling System Fluid Capacity100.4 gal
Swing Speed4 rpm

Engine

Engine specifications
Engine ModelQSK45-C
Displacement2,746 in³
Power Measured @1,800 rpm
Gross Power1,350.0 hp
Net Power1,302.0 hp
Number of Cylinders12
Aspirationturbo-charged after-cooled

Dimensions

Dimensions specifications
Height - Top of Cab277 in
Length of Track on Ground241 in
Tail Swing Radius248 in
Upper Structure Ground Clearance89 in
Length of Tracks311 in
Height of Tracks81 in

Undercarriage

Undercarriage specifications
Track Gauge198 in
Max Travel Speed1.5 mph
Number of Upper Rollers3
Loading Shovel Operating Weight533,519 lb
Loading Shovel Shoe Width39 in
Loading Shovel Ground Pressure25 psi
Number of Lower Rollers8
Backhoe Shoe Width 139 in
Backhoe Operating Weight - Shoe 1526,905 lb
Backhoe Ground Pressure - Shoe 125 psi
Number of Track Shoes per Side39
Tail Swing Radius248 in

Bucket

Bucket specifications
Reference Bucket Capacity19.70 yd³

Loading Shovel

Loading Shovel specifications
Max Dig Depth148 in
Max Dig Reach554 in
Max Cutting Height592 in
Max Dump Height408 in
Arm Crowd Force677 lb-ft
Loading Shovelstandard 15 cubic meter

Backhoe Boom / Stick 1

Backhoe Boom / Stick 1 specifications
Max Dig Depth339 in
Max Cutting Height637 in
Max Dump Height408 in
Max Reach on Ground650 in
Max Vertical Wall Dig Depth200 in
Arm Crowd Force608 lb-ft
