Hitachi
Pel-Job
EL451
Wheel Loader
5 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 5,831 lb |
|---|---|
| Fuel Capacity | 13.2 gal |
| Tire Size | 15.5/60-18-8PR (L2) tubeless nylon body |
| Hydraulic System Fluid Capacity | 11.1 gal |
| Static Tipping Weight | 3,638 lb |
| Operating Voltage | 12 V |
| Turning Radius | 120 in |
| Engine Oil Fluid Capacity | 1.5 gal |
| Rear Axle Oscillation | 16 ° |
| Alternator Supplied Amperage | 40 A |
| Front Axle/Diff Fluid Capacity | 1.2 gal |
| Rear Axle/Diff Fluid Capacity | 1.2 gal |
| Cooling System Fluid Capacity | 1.6 gal |
Engine
| Engine Model | D1503-DI-K2A |
|---|---|
| Displacement | 92 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 28.0 hp |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 8.9 gal/min |
|---|---|
| Raise Time | 5.0 s |
| Lower Time | 3.2 s |
| Dump Time | 1.0 s |
| Relief Valve Setting | 2,990 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 97 in |
| Wheelbase | 71 in |
| Width Over Tires | 60 in |
| Reach at Max Lift and Dump | 32 in |
| Length with Bucket on Ground | 163 in |
| Hinge Pin - Max Height | 107 in |
Transmission
| Max Speed - Forward | 9.3 mph |
|---|---|
| Max Speed - Reverse | 9.4 mph |
| Transmission Type | Hydrostatic transmission automatically controls power and speed with electrically controlled |
Bucket
| Bucket Capacity - heaped | 0.60 yd³ |
|---|---|
| Bucket Capacity - struck | 0.50 yd³ |
| Dump Clearance at Max Raise | 85 in |
| Breakout Force | 6,170 lb |
| Bucket Width | 62 in |
