HitachiZettelmeyer
ZL601
Wheel Loader
39 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 14,727 lb |
|---|---|
| Fuel Capacity | 37.0 gal |
| Tire Size | 15.5x25 |
| Hydraulic System Fluid Capacity | 15.9 gal |
| Static Tipping Weight | 10,979 lb |
| Operating Voltage | 24 V |
| Turning Radius | 204 in |
| Engine Oil Fluid Capacity | 4.0 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 40 A |
| Front Axle/Diff Fluid Capacity | 4.3 gal |
| Rear Axle/Diff Fluid Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 5.6 gal |
Engine
| Engine Model | W04CT |
|---|---|
| Displacement | 234 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 84.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,600 rpm |
Hydraulic System
| Pump Flow Capacity | 30.4 gal/min |
|---|---|
| Raise Time | 5.1 s |
| Lower Time | 2.5 s |
| Dump Time | 1.0 s |
| Relief Valve Setting | 3,130 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 101 in |
| Width Over Tires | 89 in |
| Reach at Max Lift and Dump | 43 in |
| Length with Bucket on Ground | 243 in |
| Hinge Pin - Max Height | 134 in |
Transmission
| Max Speed - Forward | 21.4 mph |
|---|---|
| Max Speed - Reverse | 21.4 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.60 yd³ |
|---|---|
| Bucket Capacity - struck | 1.40 yd³ |
| Dump Clearance at Max Raise | 102 in |
| Breakout Force | 15,152 lb |
