Hitachi
Case
CX75 SR
Excavator
50 specifications
1 / 5
Image 1 of 5
Specifications
57 data points
Operating Specifications
| Operating Weight | 27,600 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 55.5 gal/min |
| Hydraulic System Fluid Capacity | 34.4 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 4.2 gal |
| Cooling System Fluid Capacity | 5.1 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 0.9 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | CC-4BG1TC |
|---|---|
| Displacement | 264 in³ |
| Power Measured @ | 2,150 rpm |
| Net Power | 88.0 hp |
| Aspiration | Turbocharged intercooled |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 253 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 108 in |
| Length of Track on Ground | 114 in |
| Tail Swing Radius | 84 in |
| Width to Outside of Tracks | 107 in |
| Removal Counterweight Clearance | 36 in |
| Digging Depth | 228 in |
| Digging Reach | 228 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 78 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.4 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 44 |
| Number of Carrier Rollers per Side | 1 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 203 in |
|---|---|
| Max Reach Along Ground | 306 in |
| Max Loading Height | 235 in |
| Max Vertical Wall Digging Depth | 183 in |
| Max Cutting Height | 330 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 108 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.90 yd³ |
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 14 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 220 in |
|---|---|
| Max Vertical Wall Digging Depth | 198 in |
| Max Cutting Height | 339 in |
| Max Loading Height | 244 in |
| Max Reach Along Ground | 322 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 108 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 239 in |
|---|---|
| Max Cutting Height | 350 in |
| Max Loading Height | 256 in |
| Max Vertical Wall Digging Depth | 217 in |
| Max Reach Along Ground | 340 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 108 in |
