8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 3,790 lb |
|---|---|
| Blade height | 10 in |
Engine
| Engine Model | 3TNV74F |
|---|---|
| Displacement | 61 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 14.5 hp |
| Alternator | 40 A |
| Emission Tier Level | EPA Final Tier 4 |
Hydraulic System
| Auxiliary hydraulic flow | 7.9 gal/min |
|---|
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Tail Swing Radius | 28 in |
| Counterweight Clearance | 18 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|
Fluid Capacities
| Fuel Tank | 5.3 gal |
|---|---|
| Cooling system | 0.8 gal |
| Hydraulic Tank | 3.7 gal |
| Engine oil with filter | 0.9 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 86 in |
|---|---|
| Max Reach Along Ground | 151 in |
| Max Cutting Height | 141 in |
| Max.Dumping Height | 100 in |
| Max Digging Reach | 150 in |
| Minimum swing radius | 60 in |
Bucket
| Bucket digging Force - SAE | 3,597 lb |
|---|---|
| Arm digging Force | 1,933 lb |
Boom
| Boom swing left | 70 ° |
|---|---|
| Boom swing right | 50 ° |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Performance
| Travel speed low | 1.5 mph |
|---|---|
| Travel Speed - High | 2.7 mph |
