Hitachi
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Fuel Capacity | 18.5 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 33.0 gal/min |
| Hydraulic System Fluid Capacity | 13.3 gal |
| Alternator Supplied Amperage | 55 A |
| Engine Oil Capacity | 2.3 gal |
| Cooling System Fluid Capacity | 1.8 gal |
Engine
| Engine Model | 4TNV88 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 38.1 hp |
| Make | Yanmar |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 101 in |
| Tail Swing Radius | 40 in |
| Width to Outside of Tracks | 79 in |
| Removal Counterweight Clearance | 25 in |
| Digging Depth | 141 in |
| Digging Reach | 234 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Max Travel Speed | 2.7 mph |
| Shoe Size | 16 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 141 in |
|---|---|
| Max Reach Along Ground | 233 in |
| Max Loading Height | 156 in |
| Shipping Length of Unit | 216 in |
| Max Cutting Height | 222 in |
| Shipping Height of Unit | 101 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 152 in |
|---|---|
| Max Cutting Height | 231 in |
| Max Loading Height | 166 in |
| Max Reach Along Ground | 245 in |
| Shipping Height of Unit | 101 in |
| Shipping Length of Unit | 219 in |
