Hypac

C778D

Smooth Drum Roller

Operating Weight
25,800 lb
Max Speed
10.1 mph
Drum Width
78 in
Gross Power
130.0 hp
All smooth drum rollers
Hypac C778D Smooth Drum Roller
1 / 5
Image 1 of 5
Image: forconstructionpros.com

Specifications

24 data points

Operating Specifications

Operating Specifications specifications
Operating Weight25,800 lb
Max Speed10.1 mph
Fuel Capacity60.0 gal
Operating Voltage12 V
Engine Oil Capacity4.3 gal
Cooling System Fluid Capacity4.8 gal

Engine

Engine specifications
Engine ModelQSB4.5
Power Measured @2,200 rpm
Gross Power130.0 hp
Number of Cylinders4
MakeCummins

Dimensions

Dimensions specifications
Ground Clearance15 in
Height - Top of Cab111 in
Wheelbase10 in
Overall Length17 in
Overall Width84 in
Turning Radius - Inside198 in

Drum

Drum specifications
Drum Width78 in
Drum Diameter48 in
Vibration Frequency 167 vpm
Vibration Frequency 257 vpm
Static Linear Load14 lb-ft
Frequency3,400 – 4,000 vpm
Nominal Amplitude - Med0 in
