Hypac

C840D

Smooth Drum Roller

Operating Weight
22,930 lb
Max Speed
8.4 mph
Drum Width
84 in
Gross Power
133.0 hp
All smooth drum rollers
Hypac C840D Smooth Drum Roller
1 / 5
Image 1 of 5
Image: heavy-spec.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight22,930 lb
Max Speed8.4 mph
Fuel Capacity66.1 gal
Operating Voltage12 V

Engine

Engine specifications
Engine ModelTCD2013L042V
Power Measured @2,200 rpm
Gross Power133.0 hp
Number of Cylinders4
MakeDeutz

Dimensions

Dimensions specifications
Ground Clearance19 in
Height - Top of Cab118 in
Wheelbase10 in
Overall Length19 in
Overall Width84 in
Turning Radius - Inside138 in

Tires & Wheels

Tires & Wheels specifications
Tires23.1-26/12PR

Drum

Drum specifications
Drum Width84 in
Drum Diameter59 in
Vibration Frequency 130 vpm
Vibration Frequency 236 vpm
Static Linear Load13 lb-ft
Frequency1,800 – 2,160 vpm
Nominal Amplitude - Med0 in
