Hyster
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 8,466 lb |
|---|---|
| Max Speed | 7.1 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Front rubber rear poly 92D |
Engine
| Fuel Type | Electric |
|---|
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 44 in |
| Overall Width | 43 in |
| Turning Radius | 55 in |
| Overall Height - mast lowered | 83 in |
| Length to Fork Face | 69 in |
| Height to Top of Overhead Guard | 89 in |
| Max Fork Height | 128 in |
| Right Angle Stack | 117 in |
Mast
| Load Capacity | 3,001 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.1 mph |
| Mast Tip Forward | 5 ° |
| Mast Tip Rear | 5 ° |
| Lower Speed | 1.0 mph |
| Number of Mast Sections | 2 |
