Hyster
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 7,350 lb |
|---|---|
| Max Speed | 10.6 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Cushion |
| Drawbar Pull | 3,342 lb |
| Front Tire Size | 21 x 8 x 15 |
| Rear Tire Size | 16 x 6 x 10.5 |
| Axle load - front | 4,473 lb |
| Axle load - rear | 6,768 lb |
| Operating Voltage | 36 V |
| Auxiliary hydraulic flow | 10.6 gal/min |
Engine
| Engine Model | E60XN |
|---|---|
| Engine Make | Hyster |
| Power | 24.7 hp |
Hydraulic System
| Relief Valve Pressure | 2,250 psi |
|---|
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 55 in |
| Overall Width | 44 in |
| Turning Radius | 76 in |
| Overall Height - mast lowered | 83 in |
| Length to Fork Face | 88 in |
| Gradeability | 32.0 % |
| Height to Top of Overhead Guard | 89 in |
| Right Angle Stack | 141 in |
| Rear Tread Range | 36 in |
| Front Tread Range | 36 in |
Brakes & Steering
| Service brake | Hydraulic |
|---|---|
| Parking brake | Mechanical |
Mast
| Load Capacity | 6,001 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.1 mph |
| Mast Tip Forward | 5 ° |
| Mast Tip Rear | 5 ° |
| Lower Speed | 1.0 mph |
