Hyster
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 11,070 lb |
|---|---|
| Max Speed | 11.2 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
| Drawbar Pull | 3,327 lb |
| Front Tire Size | 22 x 9 x 16 |
| Rear Tire Size | 18 x 6 x 12.1 |
| Axle load - front | 6,728 lb |
| Axle load - rear | 9,141 lb |
Engine
| Engine Model | E80XN |
|---|---|
| Engine Make | Hyster |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 62 in |
| Overall Width | 48 in |
| Turning Radius | 86 in |
| Overall Height - mast lowered | 85 in |
| Length to Fork Face | 97 in |
| Gradeability | 14.1 % |
| Height to Top of Overhead Guard | 95 in |
| Max Fork Height | 13 in |
| Right Angle Stack | 151 in |
| Rear Tread Range | 41 in |
| Front Tread Range | 37 in |
Mast
| Load Capacity | 8,001 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.1 mph |
| Mast Tip Forward | 5 ° |
| Mast Tip Rear | 5 ° |
| Lower Speed | 1.1 mph |
| Max Fork Spread | 127 in |
