Hyster
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 6,533 lb |
|---|---|
| Max Speed | 13.4 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
| Drawbar Pull | 2,560 lb |
| Front Tire Size | 6.50 x 10 - 10 |
| Rear Tire Size | 5.00 x 8.00 |
| Axle load - front | 2,842 lb |
| Axle load - rear | 3,691 lb |
| Operating Voltage | 12 V |
Engine
| Engine Model | PSI 2.0L |
|---|---|
| Displacement | 122 in³ |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,300 rpm |
| Power | 44.0 hp |
| Fuel Type | LPG |
| Torque | 100 lb-ft |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Wheelbase | 55 in |
| Overall Width | 43 in |
| Turning Radius | 79 in |
| Overall Height - mast lowered | 84 in |
| Length to Fork Face | 90 in |
| Gradeability | 26.0 % |
| Height to Top of Overhead Guard | 85 in |
| Max Fork Height | 128 in |
| Right Angle Stack | 94 in |
Transmission
| Number of Forward / Reverse Speeds | 1 |
|---|
Mast
| Load Capacity | 3,500 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.3 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 6 ° |
| Lower Speed | 1.0 mph |
| Max Fork Spread | 38 in |
