HysterHyster
H110FT
Forklift
38 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 20,979 lb |
|---|---|
| Max Speed | 12.5 mph |
| Number of Front Wheels | — |
| Number of Rear Wheels | 2 |
| Tire Type | Cushion |
| Drawbar Pull | 10,000 lb |
| Hydraulic System Relief Valve Pressure | 2,250 psi |
| Front Tire Size | 28 x 12 x 22 |
| Rear Tire Size | 22 x 12 x 16 |
| Axle load - front | 8,179 lb |
| Axle load - rear | 12,800 lb |
| Hydraulic Tank | 19.8 gal |
Engine
| Engine Model | PSI 4.3L |
|---|---|
| Displacement | 263 in³ |
| Number of Cylinders | 6 |
| Torque Measured @ | 2,400 rpm |
| Engine Make | Kubota |
| Power | 101.0 hp |
| Torque | 220 lb-ft |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Wheelbase | 73 in |
| Overall Width | 57 in |
| Turning Radius | 102 in |
| Overall Height - mast lowered | 107 in |
| Length to Fork Face | 117 in |
| Gradeability | 27.9 % |
| Height to Top of Overhead Guard | 91 in |
| Max Fork Height | 107 in |
Mast
| Load Capacity | 13,228 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.2 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 10 ° |
| Lower Speed | 1.3 mph |
