Hyster
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 6,592 lb |
|---|---|
| Max Speed | 10.7 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Cushion |
| Drawbar Pull | 3,095 lb |
| Fuel Capacity | 10.2 gal |
| Hydraulic System Relief Valve Pressure | 2,250 psi |
| Front Tire Size | 18 X 7 X 12.125 |
| Rear Tire Size | 15 X 5 X 11.25 |
| Axle load - front | 2,731 lb |
| Axle load - rear | 3,859 lb |
| Hydraulic Tank | 8.3 gal |
Engine
| Engine Model | PSI 2.0L |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,400 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,300 rpm |
| Power | 44.0 hp |
| Fuel Type | LP/Gas |
| Torque | 100 lb-ft |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 55 in |
| Overall Width | 40 in |
| Turning Radius | 72 in |
| Overall Height - mast lowered | 83 in |
| Length to Fork Face | 84 in |
| Gradeability | 31.0 % |
| Height to Top of Overhead Guard | 79 in |
| Max Fork Height | 128 in |
| Right Angle Stack | 86 in |
Mast
| Load Capacity | 3,500 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.3 mph |
| Mast Tip Forward | 5 ° |
| Mast Tip Rear | 5 ° |
| Lower Speed | 1.1 mph |
