Hyster
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 7,802 lb |
|---|---|
| Max Speed | 11.3 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Cushion |
| Drawbar Pull | 5,322 lb |
| Fuel Capacity | 10.7 gal |
| Hydraulic System Relief Valve Pressure | 2,250 psi |
| Front Tire Size | 21 X 7 x 15 |
| Rear Tire Size | 16 x 5 x 10.5 |
| Axle load - front | 3,570 lb |
| Axle load - rear | 4,233 lb |
| Hydraulic Tank | 9.5 gal |
Engine
| Engine Model | PSI 2.4L |
|---|---|
| Displacement | 143 in³ |
| Power Measured @ | 2,700 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 2,000 rpm |
| Power | 59.0 hp |
| Fuel Type | LP/Gas |
| Torque | 121 lb-ft |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 56 in |
| Overall Width | 43 in |
| Turning Radius | 77 in |
| Overall Height - mast lowered | 85 in |
| Length to Fork Face | 89 in |
| Gradeability | 39.0 % |
| Height to Top of Overhead Guard | 84 in |
| Max Fork Height | 131 in |
| Right Angle Stack | 93 in |
Mast
| Load Capacity | 4,000 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.4 mph |
| Mast Tip Forward | 5 ° |
| Mast Tip Rear | 5 ° |
| Lower Speed | 1.3 mph |
