Hyundai
Komatsu
FD160E-8
Forklift
31 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 42,406 lb |
|---|---|
| Max Speed | 20.9 mph |
| Number of Front Wheels | 4 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic Solid |
Engine
| Engine Model | QSB6.7 |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 6 |
| Engine Make | Cummins |
| Power | 159.6 hp |
| Fuel Type | Diesel |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Wheelbase | 131 in |
| Overall Width | 98 in |
| Turning Radius | 178 in |
| Overall Height - mast lowered | 128 in |
| Length to Fork Face | 193 in |
| Height to Top of Overhead Guard | 117 in |
Mast
| Load Capacity | 35,274 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 0.8 mph |
| Mast Tip Forward | 15 ° |
| Mast Tip Rear | 12 ° |
| Lower Speed | 1.0 mph |
