Hyundai
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 8,303 lb |
|---|---|
| Max Speed | 11.5 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
Engine
| Engine Model | HMC Beta |
|---|---|
| Displacement | 121 in³ |
| Number of Cylinders | 4 |
| Power | 49.7 hp |
| Fuel Type | Gas/Petrol |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 56 in |
| Overall Width | 42 in |
| Turning Radius | 80 in |
| Overall Height - mast lowered | 86 in |
| Length to Fork Face | 91 in |
| Height to Top of Overhead Guard | 83 in |
| Max Fork Height | 131 in |
Mast
| Load Capacity | 5,000 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.2 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 10 ° |
| Lower Speed | 1.1 mph |
