Hyundai
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
15 data points
Operating Specifications
| Rated Bucket Capacity | 3.60 yd³ |
|---|
Engine
| Net Power | 197.0 hp |
|---|---|
| Make | Cummins |
Weights
| Operating Weight | 33,995 lb |
|---|
Bucket
| Dump Clearance at Max Raise | 111 in |
|---|
General Specifications
| Operating Weight | 33,995 (15,420) — Starting 2019 Model Year |
|---|---|
| Operating Weight lbs (kg) | 33,995 (15,420) — Starting 2025 Model Year |
| Bucket Capacity | 3.6 (2.8) — Starting 2019 Model Year |
| Bucket Capacity cu. yd. (cu m) | 3.6 (2.8) — Starting 2025 Model Year |
| Engine type | Cummins QSB6.7 — Starting 2019 Model Year |
| Engine Power | 197 (147) — Starting 2024 Model Year |
| Max Dump Height | 9.4(2.84) — Starting 2024 Model Year |
| Max Dump Height ft.( m) | 9.4(2.84) — Starting 2025 Model Year |
| OperatingWeight lbs. (kg) | 33,995 (15,420) — Starting 2026 Model Year |
| Engine Power Gross hp (kW) | 197 (147) — Starting 2025 Model Year |
