Hyundai
BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 26,456 lb |
|---|---|
| Max Speed | 7.8 mph |
| Fuel Capacity | 79.3 gal |
| Hydraulic System Fluid Capacity | 28.1 gal |
Engine
| Engine Model | TCD 2012 L4 |
|---|---|
| Gross Power | 130.0 hp |
| Engine Make | Deutz |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 115 in |
| Wheelbase | 126 in |
| Overall Length | 227 in |
| Overall Width | 90 in |
Tires & Wheels
| Tires | 23.1-26 |
|---|
Drum
| Drum Width | 83 in |
|---|---|
| Drum Diameter | 59 in |
| Vibration Frequency 1 | 40 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 53,954 lb |
| Vibration Frequency 2 | 140 vpm |
| Centrifugal Force - Low | 31,473 lb |
| Nominal Amplitude - Low | 0 in |
