Hyundai

HSL1500T

Skid Steer Loader

Operating Weight
10,501 lb
Gross Power
7.4 hp
All skid steer loaders
Hyundai HSL1500T Skid Steer Loader
1 / 5
Image 1 of 5
Image: filesmart.sellfy.store

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Operating Weight10,501 lb
Max Speed - low range6.8 mph
Fuel Capacity28.8 gal
Hydraulic System Fluid Capacity24.0 gal
Tire Size12x16.5
Operating Speed12.4 mph

Engine

Engine specifications
Engine ModelV3300T
Power Measured @2,700 rpm
Gross Power7.4 hp
Net Power83.0 hp

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity21.1 gal/min
Relief Valve Pressure3,000 psi
Pump Flow21.1 gal/min

Dimensions

Dimensions specifications
Ground Clearance9 in
Height - Top of Cab85 in
Wheelbase49 in
Width Over Tires71 in
Reach at Max Lift and Dump22 in
Width Over Tracks71 in
Length with Bucket146 in
Clearance at Max Lift and Dump97 in
Turning Radius from Center - inc bucket84 in
Turning Radius from Center - machine rear70 in
Length w/o Bucket118 in
Length - without Bucket118 in

Loader

Loader specifications
Operating Load Rating2,524 lb
Tipping Angle6,400 °
Operating Load3,201 lb
