Hyundai

ROBEX 16-7

Mini Excavator

Operating Weight
3,594 lb
Max Digging Depth
94 in
Net Power
17.0 hp
All mini excavators
Hyundai ROBEX 16-7 Mini Excavator
1 / 5
Image 1 of 5
Image: lectura-specs.com

Specifications

29 data points

Operating Specifications

Operating Specifications specifications
Operating Weight3,594 lb
Fuel Capacity5.3 gal
Hydraulic Pump Flow Capacity12.5 gal/min
Hydraulic System Fluid Capacity6.4 gal
Hydraulic System Relief Valve Pressure2,700 psi
Engine Oil Capacity1.0 gal
Cooling System Fluid Capacity1.5 gal

Engine

Engine specifications
Engine ModelL3E-W231
Displacement58 in³
Power Measured @2,400 rpm
Net Power17.0 hp

Dimensions

Dimensions specifications
Height - Top of Cab90 in
Length of Track on Ground44 in
Tail Swing Radius65 in
Width to Outside of Tracks52 in

Undercarriage

Undercarriage specifications
Ground Pressure4 psi
Track Gauge41 in
Max Travel Speed2.5 mph
Shoe Size9 in
Drawbar Pull2,840 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth94 in
Max Reach Along Ground155 in
Max Vertical Wall Digging Depth67 in
Max Loading Height91 in
Shipping Length of Unit148 in
Max Cutting Height133 in
Shipping Height of Unit90 in

Bucket

Bucket specifications
Reference Bucket Capacity0.10 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed12 rpm
