Ingersoll Rand
Dynapac
F5CS
Asphalt Paver
17 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Operating Weight w/ Screed | 16,958 lb |
|---|---|
| Fuel Capacity | 28.1 gal |
Engine
| Net Power | 87.0 hp |
|---|---|
| Aspiration | turbocharged |
Dimensions
| Transport Width | 103 in |
|---|---|
| Transport Height | 76 in |
| Track Width | 12 in |
| Length w/ Screed | 158 in |
| Width w/ Hopper Open | 110 in |
Hopper/Paver
| Paving Width - max | 178 in |
|---|---|
| Paving Speed - max | 1.4 mph |
| Travel Speed - max | 3.5 mph |
| Auger Diameter | 10 in |
| Paving Thickness - max | 6 in |
