Ingersoll Rand
BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 33,810 lb |
|---|---|
| Max Speed | 6.6 mph |
| Fuel Capacity | 68.0 gal |
| Operating Width | 92 in |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 35.0 gal |
| Alternator Supplied Amperage | 95 A |
Engine
| Engine Model | QSB 5.9-C |
|---|---|
| Net Power | 185.0 hp |
| Aspiration | Turbocharged & charge air-cooled 6-cylinder |
| Make | Cummins |
Dimensions
| Height - Top of Cab | 126 in |
|---|---|
| Overall Length | 12 in |
Drum
| Drum Diameter | 59 in |
|---|---|
| Vibration Frequency 1 | 42 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 44,910 lb |
| Vibration Frequency 2 | 57 vpm |
| Vibration Frequency | 2,500 – 3,400 vpm |
| Centrifugal Force - Low | 38,280 lb |
| Nominal Amplitude - Low | 0 in |
