Ingersoll Rand
Hamm
HD 10 VO
Smooth Drum Roller
40 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 5,400 lb |
|---|---|
| Max Speed | 6.3 mph |
| Fuel Capacity | 10.6 gal |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 7.1 gal |
| Alternator Supplied Amperage | 45 A |
Engine
| Engine Model | A1700 |
|---|---|
| Net Power | 32.0 hp |
Dimensions
| Height - Top of Cab | 103 in |
|---|---|
| Wheelbase | 6 in |
| Overall Length | 8 in |
| Overall Width | 43 in |
| Turning Radius - Inside | 124 in |
| Turning Radius - Outside | 152 in |
Drum
| Drum Diameter | 28 in |
|---|---|
| Vibration Frequency 1 | 55 vpm |
| Centrifugal Force - High | 8,318 lb |
| Vibration Frequency 2 | 67 vpm |
| Vibration Frequency | 4,000 vpm |
| Centrifugal Force - Low | 5,620 lb |
| Nominal Amplitude - Med | 0 in |
