Ingersoll Rand

PF2181

Asphalt Paver

Operating Weight w/ Screed
27,650 lb
Paving Width - max
252 in
Length w/ Screed
226 in
All asphalt pavers
Ingersoll Rand PF2181 Asphalt Paver
1 / 5
Image 1 of 5
Image: machinerymarketplace.net

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight w/ Screed27,650 lb
Operating Weight w/o Screed24,400 lb
Fuel Capacity53.9 gal
Hydraulic System Fluid Capacity53.9 gal
Operating Voltage12 V
Cooling System Fluid Capacity6.4 gal
Alternator Supplied Amperage130 A

Engine

Engine specifications
Engine ModelQSB 5.9-30T
Power Measured @2,100 rpm
Net Power158.0 hp

Dimensions

Dimensions specifications
Wheelbase90 in
Transport Width100 in
Transport Height125 in
Length w/ Screed226 in
Width w/ Hopper Open125 in

Hopper/Paver

Hopper/Paver specifications
Paving Width - max252 in
Paving Speed - max3.0 mph
Hopper Capacity7 lb
Travel Speed - max8.6 mph
Auger Diameter16 in
Paving Thickness - max12 in
