Ingersoll Rand
PF3200
- Operating Weight w/ Screed
- 32,700 lb
- Paving Width - max
- 360 in
- Length w/ Screed
- 251 in
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight w/ Screed | 32,700 lb |
|---|---|
| Operating Weight w/o Screed | 29,500 lb |
| Fuel Capacity | 53.9 gal |
| Hydraulic System Fluid Capacity | 53.9 gal |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 7.1 gal |
| Alternator Supplied Amperage | 130 A |
Engine
| Engine Model | QSB 5.9-30TAA |
|---|---|
| Net Power | 188.0 hp |
Dimensions
| Wheelbase | 125 in |
|---|---|
| Transport Width | 121 in |
| Transport Height | 125 in |
| Length w/ Screed | 251 in |
| Width w/ Hopper Open | 125 in |
Hopper/Paver
| Paving Width - max | 360 in |
|---|---|
| Paving Speed - max | 3.1 mph |
| Hopper Capacity | 8 lb |
| Travel Speed - max | 10.9 mph |
| Auger Diameter | 16 in |
| Paving Thickness - max | 12 in |
