Ingersoll Rand
PF6170
- Operating Weight w/ Screed
- 40,652 lb
- Paving Width - max
- 312 in
- Length w/ Screed
- 206 in
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight w/ Screed | 40,652 lb |
|---|---|
| Operating Weight w/o Screed | 36,122 lb |
| Fuel Capacity | 80.0 gal |
| Hydraulic System Fluid Capacity | 62.5 gal |
Engine
| Engine Model | QSB 6.7 Tier 3 |
|---|---|
| Power Measured @ | 1,800 rpm |
| Net Power | 205.0 hp |
Dimensions
| Wheelbase | 103 in |
|---|---|
| Transport Width | 119 in |
| Transport Height | 141 in |
| Tire Size | 18x25 |
| Length w/ Screed | 206 in |
| Width w/ Hopper Open | 130 in |
Hopper/Paver
| Paving Width - max | 312 in |
|---|---|
| Paving Speed - max | 3.4 mph |
| Hopper Capacity | 9 lb |
| Travel Speed - max | 12.0 mph |
| Auger Diameter | 17 in |
| Paving Thickness - max | 12 in |
