Ingersoll Rand
BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 35,200 lb |
|---|---|
| Max Speed | 7.8 mph |
| Fuel Capacity | 68.0 gal |
| Operating Width | 95 in |
| Hydraulic System Fluid Capacity | 27.0 gal |
Engine
| Engine Model | B5.9-TAA |
|---|---|
| Net Power | 173.0 hp |
| Aspiration | turbocharged |
| Make | Cummins |
Dimensions
| Height - Top of Cab | 124 in |
|---|---|
| Wheelbase | 10 in |
| Overall Length | 20 in |
| Overall Width | 95 in |
| Turning Radius - Inside | 136 in |
Tires & Wheels
| Tires | 23.1x26-8PR R3 |
|---|
Drum
| Drum Diameter | 63 in |
|---|---|
| Vibration Frequency 1 | 34 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 76,210 lb |
| Vibration Frequency 2 | 31 vpm |
| Vibration Frequency | 1,850 – 2,025 vpm |
| Centrifugal Force - Low | 59,350 lb |
| Nominal Amplitude - Low | 0 in |
