Ingersoll Rand

SD-160DXTF

Smooth Drum Roller

Operating Weight
35,195 lb
Max Speed
7.8 mph
Drum Width
84 in
Gross Power
173.0 hp
All smooth drum rollers
Ingersoll Rand SD-160DXTF Smooth Drum Roller
1 / 5
Image 1 of 5
Image: veritread.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight35,195 lb
Max Speed7.8 mph
Fuel Capacity67.9 gal
Operating Voltage12 V
Hydraulic System Fluid Capacity27.5 gal
Alternator Supplied Amperage95 A

Engine

Engine specifications
Engine ModelB5.9-TAA
Gross Power173.0 hp

Dimensions

Dimensions specifications
Ground Clearance21 in
Height - Top of Cab124 in
Wheelbase10 in
Overall Length20 in
Overall Width98 in

Tires & Wheels

Tires & Wheels specifications
Tires23.1x26-8PR R3

Drum

Drum specifications
Drum Width84 in
Drum Diameter63 in
Vibration Frequency 120 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High76,210 lb
Vibration Frequency 234 vpm
Centrifugal Force - Low59,350 lb
Nominal Amplitude - Low0 in
