Ingersoll Rand

SD-200DXTF

Smooth Drum Roller

Operating Weight
44,992 lb
Max Speed
7.9 mph
Drum Width
84 in
Gross Power
205.0 hp
All smooth drum rollers
Ingersoll Rand SD-200DXTF Smooth Drum Roller
1 / 5
Image 1 of 5
Image: gappower.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight44,992 lb
Max Speed7.9 mph
Fuel Capacity67.9 gal
Operating Voltage12 V
Hydraulic System Fluid Capacity27.5 gal
Alternator Supplied Amperage95 A

Engine

Engine specifications
Engine ModelQSB5.9-TAA
Gross Power205.0 hp

Dimensions

Dimensions specifications
Ground Clearance19 in
Height - Top of Cab124 in
Wheelbase11 in
Overall Length21 in
Overall Width98 in

Tires & Wheels

Tires & Wheels specifications
Tires23.1x26-10PR R3

Drum

Drum specifications
Drum Width84 in
Drum Diameter65 in
Vibration Frequency 120 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High82,730 lb
Vibration Frequency 231 vpm
Centrifugal Force - Low53,729 lb
Nominal Amplitude - Low0 in
