Ingersoll Rand
Dynapac
CG233HF
Smooth Drum Roller
19 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 16,350 lb |
|---|---|
| Max Speed | 9.1 mph |
| Fuel Capacity | 47.1 gal |
| Operating Width | 74 in |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 22.2 gal |
| Alternator Supplied Amperage | 105 A |
Engine
| Engine Model | B4.5T Tier 2 |
|---|---|
| Net Power | 99.0 hp |
| Aspiration | turbocharged |
| Make | Cummins |
Dimensions
| Height - Top of Cab | 115 in |
|---|---|
| Wheelbase | 9 in |
| Overall Length | 17 in |
| Overall Width | 74 in |
| Turning Radius - Inside | 128 in |
Tires & Wheels
| Tires | 14.9x24 -6PR R3 |
|---|
Drum
| Drum Width | 66 in |
|---|---|
| Drum Diameter | 48 in |
| Vibration Frequency 1 | 20 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 32,148 lb |
| Vibration Frequency 2 | 34 vpm |
| Vibration Frequency | 1,850 – 2,025 vpm |
| Centrifugal Force - Low | 23,380 lb |
| Nominal Amplitude - Low | 0 in |
