JCB
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 5,534 lb |
|---|---|
| Max Speed | 6.9 mph |
| Fuel Capacity | 21.0 gal |
| Hydraulic System Fluid Capacity | 7.9 gal |
| Tire Size | 10 x 16.5 - 6 pr Wide Track |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 A |
| Engine Oil Fluid Capacity | 2.5 gal |
| Cooling System Fluid Capacity | 2.1 gal |
| Chain Box Fluid Capacity - each side | 4.5 gal |
Engine
| Engine Model | 404C-22 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Number of Cylinders | 4 |
| Aspiration | Naturally aspirated |
Hydraulic System
| Pump Flow Capacity | 15.9 gal/min |
|---|---|
| Relief Valve Pressure | 2,683 psi |
| Pump Type | Hydrostatic drive pumps |
Dimensions
| Height - Top of Cab | 77 in |
|---|---|
| Wheelbase | 41 in |
| Width Over Tires | 64 in |
| Reach at Max Lift and Dump | 19 in |
| Length with Bucket | 130 in |
| Clearance at Max Lift and Dump | 91 in |
| Turning Radius from Center - inc bucket | 78 in |
| Turning Radius from Center - machine rear | 64 in |
| Length w/o Bucket | 96 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,543 lb |
| Tipping Angle | 3,086 ° |
| Breakout Force | 3,197 psi |
