JCB
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 8,865 lb |
|---|---|
| Fuel Capacity | 25.9 gal |
| Hydraulic System Fluid Capacity | 11.5 gal |
| Cooling System Fluid Capacity | 2.7 gal |
| Engine Oil Capacity | 2.0 gal |
Engine
| Engine Model | Kohler - KDI2504TCR/26A |
|---|---|
| Displacement | 152 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 73.8 hp |
| Aspiration | Turbo |
| Torque Measured @ | 1,200 rpm |
| Alternator | 100 A |
| Emissions Certification | EPA-T4F (EU St3B) |
| Cooling system | Liquid |
| Battery | 12 V |
| Peak Torque | 221 lb-ft |
| Fuel | Diesel |
| Engine oil service interval hours | 500 |
| Starter motor | 2.0 hp |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 79 in |
| Reach at Max Lift and Dump | 40 in |
| Width Over Tracks | 67 in |
| Length with Bucket | 138 in |
| Clearance at Max Lift and Dump | 120 in |
| Dump Height | 91 in |
| Angle of departure | 27 ° |
Transmission
| Travel Speed | 6.3 mph |
|---|
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Tipping Angle | 5,298 ° |
| Operating Load | 8,865 lb |
| Breakout Force | — |
| Bucket Width | 66 in |
