JCB
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Operating Weight | 15,439 lb |
|---|
General Specifications
| Operating Weight lbs (kg) | 15,439 (7,005) — Starting 2004 Model Year |
|---|---|
| Lift Capacity lbs (kgs) | 6,750 (3,062) — Starting 2004 Model Year |
| Loading Height ft (m) | 10.5 (3.2) — Starting 2004 Model Year |
| 4th Gear Fwd mph (kmh) | 21 (33.8) — Starting 2004 Model Year |
| Breakout Force lbs (kgs) | 12,000 (5,445) — Starting 2004 Model Year |
| Digging Depth ft (m) | 14.6 (4.45) — Starting 2004 Model Year |
| SAE Net hp (kW) | 86 (64) — Starting 2004 Model Year |
Backhoe
| Max Digging Depth | 175 in |
|---|---|
| Loading Height | 126 in |
Loader
| Lift Capacity | 6,750 lb |
|---|---|
| SAE - Net | 86.0 hp |
| Breakout Force | — |
Travel Speed
| 4th Gear Fwd | 21.0 mph |
|---|
