JCB

260T

Compact Track Loader

Operating Weight
10,205 lb
Displacement
268 in³
Gross Power
84.0 hp
All compact track loaders
JCB 260T Compact Track Loader
1 / 5
Image 1 of 5
Image: makana.com

Specifications

26 data points

Operating Specifications

Operating Specifications specifications
Operating Weight10,205 lb
Max Speed - low range5.7 mph
Fuel Capacity27.3 gal
Hydraulic System Fluid Capacity15.9 gal
Cooling System Fluid Capacity4.1 gal
Operating Voltage12 V
Engine Oil Capacity3.7 gal

Engine

Engine specifications
Engine ModelDieselmax TC-63
Displacement268 in³
Power Measured @2,400 rpm
Gross Power84.0 hp
AspirationTurbocharged
Torque Measured @1,800 rpm
Peak Torque267 lb-ft

Hydraulic System

Hydraulic System specifications
Pump Flow23.0 gal/min
Relief Valve Pressure3,335 psi

Dimensions

Dimensions specifications
Ground Clearance10 in
Height - Top of Cab83 in
Reach at Max Lift and Dump35 in
Width Over Tracks78 in
Length with Bucket146 in
Clearance at Max Lift and Dump96 in

Undercarriage

Undercarriage specifications
Ground Pressure5 psi
Width of Track18 in

Loader

Loader specifications
Bucket Capacity0.80 yd³
Tipping Angle7,991 °
