JCB
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Fuel Capacity | 42.3 gal |
|---|---|
| Hydraulic System Fluid Capacity | 34.9 gal |
| Cooling System Fluid Capacity | 4.9 gal |
| Tire Size Front - 2wd / 4wd | 14.9/14x24 12PR Industrial |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 4.0 gal |
| Alternator Supplied Amperage | 95 A |
| Transmission Fluid Capacity | 4.3 gal |
| Max Weight | 18,550 lb |
| Rear Axle Fluid Capacity | 4.3 gal |
| Front Axle Fluid Capacity | 4.3 gal |
Engine
| Displacement | 269 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 92.0 hp |
| Net Power | 90.1 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,300 rpm |
| Net Max Torque | 282 lb-ft |
Hydraulic System
| Pump Flow Capacity | 20.9 gal/min |
|---|---|
| Relief Valve Pressure | 3,650 psi |
| Pump Type | open centre system w/ twin gear pumps and hydraulic speed control |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 88 in |
| Transport Width | 89 in |
| Transport Length | 233 in |
| Height to Top of Suspended Cab | 113 in |
Transmission
| Max Speed | 19.9 mph |
|---|---|
| Max Speed - Reverse | 19.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | syncroshuttle |
Tires & Wheels
| Rear Tires Size | 14.9/14x24 12PR Industrial |
|---|
Backhoe
| Dig Depth | 173 in |
|---|---|
| Reach From Swivel | 214 in |
| Dig Depth - Extended | 221 in |
| Load Height - Extended | 185 in |
| Bucket Dig Force | 11,847 lb |
| Reach From Swivel - Extended | 258 in |
| Reach at Load Height - Extended | 149 in |
| Bucket Dig Force - Extended | 11,847 lb |
Loader
| Bucket Capacity | 1.40 yd³ |
|---|---|
| Clearance at Max Dump Height | 104 in |
| Bucket Width | 88 in |
