JCB
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 19,958 lb |
|---|---|
| Fuel Capacity | 30.7 gal |
| Hydraulic System Fluid Capacity | 41.0 gal |
| Operating Voltage | 24 V |
| Turning Radius | 215 in |
| Rear Axle Oscillation | 11 ° |
| Alternator Supplied Amperage | 100 A |
| DEF tank capacity | 5.3 gal |
| Articulation Angle | 40 ° |
| Payload | 6,191 lb |
| Full Turn Tipping Load | 12,381 lb |
| Auxiliary fuel tank | 29.4 gal |
Engine
| Engine Model | JCB EcoMAX T4F |
|---|---|
| Displacement | 293 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 145.2 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbo charged |
| Torque Measured @ | 1,500 rpm |
| Emission Tier Level | Tier 4 Final |
| Air cleaner | Cyclonic pre filter with engine fan scavenge system |
| No. of Valves | 4 |
Hydraulic System
| Pump Flow Capacity | 41.3 gal/min |
|---|---|
| Raise Time | 4.4 s |
| Lower Time | 2.8 s |
| Dump Time | 1.7 s |
| Relief Valve Setting | 3,190 psi |
| Pump Type | Variable placement piston pump |
| Total cycle | 8.9 s |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 121 in |
| Wheelbase | 109 in |
| Width Over Tires | 94 in |
| Reach at Max Lift and Dump | 37 in |
| Length with Bucket on Ground | 258 in |
| Hinge Pin - Max Height | 142 in |
Transmission
| Max Speed - Forward | 31.1 mph |
|---|---|
| Max Speed - Reverse | 24.4 mph |
| Transmission Type | 6 speed non-lock up converter ZF 6WG115 |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.60 yd³ |
|---|---|
| Bucket Capacity - struck | 1.40 yd³ |
| Dump Clearance at Max Raise | 110 in |
| Breakout Force | 16,456 lb |
| Bucket Width | 89 in |
