JCB
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 22,172 lb |
|---|---|
| Fuel Capacity | 30.7 gal |
| Hydraulic System Fluid Capacity | 41.0 gal |
| Operating Voltage | 24 V |
| Turning Radius | 233 in |
| Rear Axle Oscillation | 11 ° |
| Alternator Supplied Amperage | 100 A |
| DEF tank capacity | 5.3 gal |
| Articulation Angle | 40 ° |
| Auxiliary fuel tank | 29.4 gal |
Engine
| Engine Model | JCB EcoMAX T4F |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 125.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbo charged |
| Torque Measured @ | 1,500 rpm |
| Stroke | 5 in |
| Bore | 4 in |
| Engine Type | 4 stroke direct injection |
Hydraulic System
| Pump Flow Capacity | 41.3 gal/min |
|---|---|
| Raise Time | 4.9 s |
| Lower Time | 3.3 s |
| Dump Time | 2.1 s |
| Relief Valve Setting | 3,190 psi |
| Pump Type | Variable placement piston pump |
| Total cycle | 10.3 s |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 122 in |
| Wheelbase | 110 in |
| Width Over Tires | 93 in |
| Reach at Max Lift and Dump | 43 in |
| Length with Bucket on Ground | 282 in |
| Hinge Pin - Max Height | 174 in |
Transmission
| Max Speed - Forward | 31.1 mph |
|---|---|
| Max Speed - Reverse | 23.7 mph |
| Transmission Type | Smooth shift Powershift ZF 4WG115 |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.90 yd³ |
|---|---|
| Bucket Capacity - struck | 1.60 yd³ |
| Dump Clearance at Max Raise | 142 in |
| Breakout Force | 15,737 lb |
| Bucket Width | 95 in |
