JCB
Mecalac
AS 700
Wheel Loader
32 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Fuel Capacity | 60.8 gal |
|---|---|
| Tire Size | 20.5x25x12 ply (L2) |
| Hydraulic System Fluid Capacity | 55.5 gal |
| Static Tipping Weight | 21,907 lb |
| Operating Voltage | 24 V |
| Turning Radius | 231 in |
| Engine Oil Fluid Capacity | 3.9 gal |
| Rear Axle Oscillation | 25 ° |
| Alternator Supplied Amperage | 55 A |
| Front Axle/Diff Fluid Capacity | 10.4 gal |
| Rear Axle/Diff Fluid Capacity | 9.6 gal |
| Cooling System Fluid Capacity | 13.3 gal |
| Transmission Fluid Capacity | 6.4 gal |
Engine
| Engine Model | 1006-60TW |
|---|---|
| Displacement | 365 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 160.0 hp |
| Net Power | 144.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 67.4 gal/min |
|---|---|
| Raise Time | 5.0 s |
| Lower Time | 3.5 s |
| Dump Time | 1.4 s |
| Relief Valve Setting | 3,625 psi |
| Pump Type | variable displacement piston pumps with load sensing |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 119 in |
| Width Over Tires | 103 in |
| Reach at Max Lift and Dump | 42 in |
| Length with Bucket on Ground | 268 in |
| Hinge Pin - Max Height | 158 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Max Speed - Reverse | 15.0 mph |
| Transmission Type | semi-autoshift full powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.10 yd³ |
|---|---|
| Dump Clearance at Max Raise | 117 in |
| Breakout Force | 34,396 lb |
| Bucket Width | 107 in |
