JCB
Kubota
L48
Backhoe Loader
Specifications pending
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Fuel Capacity | 42.3 gal |
|---|---|
| Hydraulic System Fluid Capacity | 34.9 gal |
| Cooling System Fluid Capacity | 4.9 gal |
| Tire Size Front - 2wd / 4wd | 16.9x28 10PR Industrial |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 4.0 gal |
| Alternator Supplied Amperage | 95 A |
| Transmission Fluid Capacity | 4.3 gal |
| Rear Axle Fluid Capacity | 4.3 gal |
| Front Axle Fluid Capacity | 4.3 gal |
Engine
| Displacement | 269 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 81.0 hp |
| Net Power | 97.6 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,300 rpm |
| Net Max Torque | 381 lb-ft |
Hydraulic System
| Pump Flow Capacity | 21.4 gal/min |
|---|---|
| Relief Valve Pressure | 3,650 psi |
| Pump Type | open centre systen with twin gear pumps and hydraulic speed control |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 88 in |
| Transport Width | 94 in |
| Transport Length | 233 in |
| Height to Top of Suspended Cab | 114 in |
Transmission
| Max Speed | 23.7 mph |
|---|---|
| Max Speed - Reverse | 23.7 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | powershift |
Tires & Wheels
| Rear Tires Size | 16.9x28 10PR Industrial |
|---|
Backhoe
| Dig Depth | 170 in |
|---|---|
| Reach From Swivel | 214 in |
| Dig Depth - Extended | 219 in |
| Load Height - Extended | 169 in |
| Bucket Dig Force | 11,851 lb |
| Reach at Load Height - Extended | 149 in |
| Bucket Dig Force - Extended | 11,851 lb |
Loader
| Bucket Capacity | 1.80 yd³ |
|---|---|
| Clearance at Max Dump Height | 107 in |
| Bucket Breakout Force | 13,699 lb |
| Bucket Width | 88 in |
| Reach at Max Dump Height | 48 in |
| Dig Depth | 6 in |
Electrical System
| Alternator | — |
|---|---|
| Battery | 1000 CCA (120 amp) |
| Front working lights | 4 adjustable |
| Gauges | Tachometer engine coolant temp fuel level hourmeter clock |
| Pre-wire | Radio speakers (cab) beacon (all) |
| Rear working lights | 4 adjustable |
