Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Fuel Capacity | 55.5 gal |
|---|---|
| Tire Size | 20.5 R25 |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 8.7 gal |
| Hydraulic System Fluid Capacity | 42.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Transmission Fluid Capacity | 10.8 gal |
Engine
| Engine Model | QSB 6 |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 260.0 hp |
| Net Power | 242.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbo/charged cooled |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 730 lb-ft |
Weights
| Total Empty | 34,613 lb |
|---|---|
| Front Axle - empty | 16,535 lb |
| Total Loaded | 78,705 lb |
| Rear Axle - empty | 18,078 lb |
| Front Axle - loaded | 25,287 lb |
| Rear Axle - loaded | 53,572 lb |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 200 in |
| Overall Length | 362 in |
| Overall Width | 106 in |
| Overall Height | 137 in |
| Dump Height | 235 in |
| Dump Ground Clearance | 25 in |
Transmission
| Max Speed | 31.1 mph |
|---|---|
| Transmission Type | Smoothshift |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Dump
| Rated Payload | 44,092 lb |
|---|---|
| Dump Angle | 74 ° |
| Raise Time | 13.0 s |
| Lower Time | 11.0 s |
| Capacity - Heaped | 15.70 yd³ |
